Ahuja 250VA Central Mixer Amplifier, CMA-5400
Original price was: ₹33,235.00.₹29,911.00Current price is: ₹29,911.00.
-Highly sensitive 18.5″ (47cm) long gooseneck microphone for comfortable sharing by two delegates. -Bright and uniform band LED indicator. -Chairman/Delegate Units have attractive and well contoured plastic top for superior appearance. -Rugged and compact die cast aluminium base for better stability of Chairman/Delegate Units. -Adjustable headphone output available from each Chairman/Delegate Unit. -Automatic Mic Off feature in Delegate units which is selectable through a switch in the Central Amplifier. -Chairman Unit has Priority Switch. -Central Amplifier has a digital recorder for recording the proceedings. Also it can playback the pre-recorded messages. -Switchable send/return facility in Central Amplifier. -Three Mic inputs and one Aux input for various user applications. -50W PA Amplifier for adequate sound reinforcement. -Headphone output provided in Central Amplifier for monitoring purposes. -AC Mains & 24V DC operation. -Central Amplifier is 19″ rack mountable. -Central Amplifier has the facility of feeding two independent groups of Delegate Units as required in large conference setups. -Conference System can be installed in a bus bar arrangement by using Junction Boxes CB-45.
| Model | Ahuja CMA-5400 Central Mixer Amplifier |
| Compatibility | Designed for the CM-5000 series conference system |
| Power Output | 50W RMS at 2% THD, 90W Max |
| Frequency Response | 60–14,000Hz (±3dB) |
| Signal-to-Noise Ratio | >60dB |
| Tone Controls | Bass: -10dB at 100Hz; Treble: -10dB at 10kHz |
| Inputs | 3 × Mic (0.65mV/4.7kΩ); 1 × Aux (100mV/470kΩ) |
| Outputs | Preamp Output: 200mV/600Ω; Line Output: 1V/1kΩ; Send Output: 200mV/600Ω; Return Input: 200mV/10kΩ; Speaker Output: 4Ω, 8Ω, 16Ω, 70V & 100V |
| Power Supply | AC: 220–240V, 50/60Hz; DC: 24V (2 × 12V Car Battery) |
| Power Consumption | 250VA |
| Protections | AC Fuse: 1 × 3 Amp; DC Fuse: 2 × 10 Amp |
| Dimensions | W483 × H110 × D325 mm |
| Weight | 10.50 kg |
| Additional Features | Digital recorder for recording and playback of proceedings; Switchable send/return facility; Headphone output for monitoring purposes; 19″ rack mountable; Facility to feed two independent groups of Delegate Units; Conference system can be installed in a bus bar arrangement using Junction Boxes CB-45 |
